Azure-IoT-SDK with W5100, W5500, RP2040, NonOS

1. 🎯 Azure-IoT-SDK

AppDescription

Azure IoT SDK example Basic Azure cloud functions with Azure IoT SDK. (NonOS + WIZnet W5100S)

1.1. 3rd party SDKs

2. 🎓 Getting started

See Getting Started with the Raspberry Pi Pico and the README in the pico-sdk for information on getting up and running.

2.1. 📚 Download SDK library

2.1.1. Download azure-iot-sdk-c library

This repo get the local copy version for this project.

If you need, you can get this version from releae section in the git repo

2.1.2. Download mbedtls library

This repo get the local copy version for this project.

If you need, you can get this version from release section in their git repo

2.1.3. Building mbedtls library

For this project, (MUST) Need to change 2 files. - temporary fix In the following mbedtls source file, find the line similar to this and replace it as follows:

  1. \mbedtls-3.0.0\include\mbedtls\ssl.h

// NOTICE! temporary solution for this project tlsio_mbedtls.c // int MBEDTLS_PRIVATE(out_msgtype); /*!< record header: message type */ int out_msgtype; /*!< record header: message type */

  1. \mbedtls-3.0.0\include\mbedtls\x509_crt.h

// NOTICE! temporary solution for this project tlsio_mbedtls.c // int MBEDTLS_PRIVATE(version); /**< The X.509 version. (1=v1, 2=v2, 3=v3) */ int version; /**< The X.509 version. (1=v1, 2=v2, 3=v3) */

2.2. 🗂 Build a sample

2.2.1. Make "port" directory for Azure IoT SDK, mbedtls

For Pico W5100S platform, we need to make port codes, please check out the Microsoft Azure SDK porting guide document.

From upper porting guide, the repo has a example pico-azure-iot-sdk-c\port directory for this sample applications.

2.2.2. Modify CMakeLists.txt

In the following pico-azure-iot-sdk-c/CMakeLists.txt file, find the line similar to this and replace it as your environment:

if(NOT DEFINED MBEDTLS_LIB_DIR)
#    set(MBEDTLS_LIB_DIR ${CMAKE_CURRENT_SOURCE_DIR}/mbedtls)
    set(MBEDTLS_LIB_DIR ${CMAKE_CURRENT_SOURCE_DIR}/mbedtls-3.0.0)
#    set(MBEDTLS_LIB_DIR ${CMAKE_CURRENT_SOURCE_DIR}/mbedtls-2.27.0)
    message(STATUS "MBEDTLS_LIB_DIR = ${MBEDTLS_LIB_DIR}")
endif()
if(NOT DEFINED AZURE_SDK_DIR)
    #set(AZURE_SDK_DIR ${CMAKE_CURRENT_SOURCE_DIR}/azure-iot-sdk-c-1.4.1)
    set(AZURE_SDK_DIR ${CMAKE_CURRENT_SOURCE_DIR}/azure-iot-sdk-c-LTS_07_2021_Ref01)
    message(STATUS "AZURE_SDK_DIR = ${AZURE_SDK_DIR}")
endif()
if(NOT DEFINED PORT_DIR)
    set(PORT_DIR ${CMAKE_CURRENT_SOURCE_DIR}/port)
    message(STATUS "PORT_DIR = ${PORT_DIR}")
endif()
if(NOT DEFINED WIZNET_DIR)
    set(WIZNET_DIR ${CMAKE_CURRENT_SOURCE_DIR}/ioLibrary_Driver)
    message(STATUS "WIZNET_DIR = ${WIZNET_DIR}")
endif()



2.2.3. Set your board network information and select application

In the following pico-azure-iot-sdk-c/application/main.c source file, find the line similar to this and replace it as you want:

(...)

// The application you wish to use should be uncommented
//
#define APP_TELEMETRY
//#define APP_C2D
//#define APP_CLI_X509
//#define APP_PROV_X509

(...)

// The application you wish to use DHCP mode should be uncommented
#define _DHCP
static wiz_NetInfo g_net_info =
    {
        .mac = {0x00, 0x08, 0xDC, 0x12, 0x34, 0x11}, // MAC address
        .ip = {192, 168, 3, 111},                    // IP address
        .sn = {255, 255, 255, 0},                    // Subnet Mask
        .gw = {192, 168, 3, 1},                      // Gateway
        .dns = {8, 8, 8, 8},                         // DNS server
#ifdef _DHCP
        .dhcp = NETINFO_DHCP                         // DHCP enable/disable
#else
        // this example uses static IP
        .dhcp = NETINFO_STATIC
#endif



2.2.4. Set the key information

Edit the pico-azure-iot-sdk-c/application/sample_certs.c entering the proper connection string and key value from the Azure Portal:

/* Paste in the your iothub connection string  */
const char pico_az_connectionString[] = "[device connection string]";
const char pico_az_x509_connectionString[] = "[device connection string]";
const char pico_az_x509certificate[] =
"-----BEGIN CERTIFICATE-----""\n"
"-----END CERTIFICATE-----";
const char pico_az_x509privatekey[] =
"-----BEGIN PRIVATE KEY-----""\n"
"-----END PRIVATE KEY-----";
const char pico_az_COMMON_NAME[] = "[custom-hsm-example]";
const char pico_az_CERTIFICATE[] =
"-----BEGIN CERTIFICATE-----""\n"
"-----END CERTIFICATE-----";
const char pico_az_PRIVATE_KEY[] =
"-----BEGIN PRIVATE KEY-----""\n"
"-----END PRIVATE KEY-----";



2.3.  Build project

2.3.1. Build command

Run the following CMake commands from the root of the repository:

mkdir build
cd build

# As your environment, select
  cmake .. -G "MSYS Makefiles" ## on MSYS2 (MinGW64) + Windows 10 Platform
# OR
  cmake .. -G "Visual Studio 15 2017" ## For Visual Studio 2017
# or
  cmake .. -G "Visual Studio 16 2019" -A Win32
# or
  cmake ..

cd pico-azure-iot-sdk-c
make

Then, copy generated "main.uf2" file into your RP-Pico board. Done!!



2.3.2. Example command log

on MSYS2 (MinGW64) + Windows 10 Platform

(PWD) pico-examples/build
$ cd ..

(PWD) pico-examples
$ rm -rf build

(PWD) pico-examples
$ mkdir build

(PWD) pico-examples
$ cd build

(PWD) pico-examples/build
$ cmake .. -G "MSYS Makefiles"
-- PICO_SDK_PATH = /../../RP2040/pico-sdk
PICO_SDK_PATH is pico-sdk
Defaulting PICO_PLATFORM to rp2040 since not specified.
Defaulting PICO platform compiler to pico_arm_gcc since not specified.
-- Defaulting build type to 'Release' since not specified.
PICO compiler is pico_arm_gcc
-- The C compiler identification is GNU 10.1.0
-- The CXX compiler identification is GNU 10.1.0
-- The ASM compiler identification is GNU
-- Found assembler: C:/msys64/mingw64/bin/arm-none-eabi-gcc.exe
Defaulting PICO target board to pico since not specified.
Using board configuration from pico-sdk/src/boards/include/boards/pico.h
-- Found Python3: C:/Users/User1/AppData/Local/Programs/Python/Python39/python.exe (found version "3.9.7") found components: Interpreter
TinyUSB available at pico-sdk/lib/tinyusb/src/portable/raspberrypi/rp2040; adding USB support.
-- MBEDTLS_LIB_DIR = pico-examples/pico-azure-iot-sdk-c/mbedtls-3.0.0
-- AZURE_SDK_DIR = pico-examples/pico-azure-iot-sdk-c/azure-iot-sdk-c-1.4.1
-- PORT_DIR = pico-examples/pico-azure-iot-sdk-c/port
-- WIZNET_DIR = pico-examples/pico-azure-iot-sdk-c/ioLibrary_Driver
-- Performing Test C_COMPILER_SUPPORTS_WFORMAT_SIGNEDNESS
-- Performing Test C_COMPILER_SUPPORTS_WFORMAT_SIGNEDNESS - Failed
-- Configuring done
-- Generating done
-- Build files have been written to: pico-examples/build

(PWD) pico-examples/build
$ cd pico-azure-iot-sdk-c/

(PWD) pico-examples/build/pico-azure-iot-sdk-c
$ make
[  0%] Creating directories for 'ELF2UF2Build'
[  1%] No download step for 'ELF2UF2Build'
[  1%] No update step for 'ELF2UF2Build'
[  1%] No patch step for 'ELF2UF2Build'
[  1%] Performing configure step for 'ELF2UF2Build'
-- The C compiler identification is GNU 10.3.0
-- The CXX compiler identification is GNU 10.3.0
-- Detecting C compiler ABI info
-- Detecting C compiler ABI info - done
-- Check for working C compiler: C:/msys64/mingw64/bin/gcc.exe - skipped
-- Detecting C compile features
-- Detecting C compile features - done
-- Detecting CXX compiler ABI info
-- Detecting CXX compiler ABI info - done
-- Check for working CXX compiler: C:/msys64/mingw64/bin/g++.exe - skipped
-- Detecting CXX compile features
-- Detecting CXX compile features - done
-- Configuring done
-- Generating done
-- Build files have been written to: pico-examples/build/elf2uf2
[  1%] Performing build step for 'ELF2UF2Build'
[ 50%] Building CXX object CMakeFiles/elf2uf2.dir/main.cpp.obj
[100%] Linking CXX executable elf2uf2.exe
[100%] Built target elf2uf2
[  1%] No install step for 'ELF2UF2Build'
[  1%] Completed 'ELF2UF2Build'
[  1%] Built target ELF2UF2Build
Scanning dependencies of target bs2_default
[  1%] Building ASM object pico-sdk/src/rp2_common/boot_stage2/CMakeFiles/bs2_default.dir/compile_time_choice.S.obj
[  1%] Linking ASM executable bs2_default.elf
[  1%] Built target bs2_default
[  1%] Generating bs2_default.bin
[  2%] Generating bs2_default_padded_checksummed.S
[  2%] Built target bs2_default_padded_checksummed_asm
Scanning dependencies of target W5100S_FILES
[  3%] Building C object pico-azure-iot-sdk-c/ioLibrary_Driver/Ethernet/W5100S/CMakeFiles/W5100S_FILES.dir/w5100s.c.obj
[  3%] Building C object pico-azure-iot-sdk-c/ioLibrary_Driver/Ethernet/W5100S/CMakeFiles/W5100S_FILES.dir/D_/RP2040/pico-sdk/src/rp2_common/pico_stdlib/stdlib.c.obj

(...)

[100%] Building C object pico-azure-iot-sdk-c/CMakeFiles/main.dir/D_/RP2040/pico-sdk/src/rp2_common/hardware_flash/flash.c.obj
[100%] Building C object pico-azure-iot-sdk-c/CMakeFiles/main.dir/D_/RP2040/pico-sdk/src/rp2_common/hardware_spi/spi.c.obj
[100%] Linking CXX executable main.elf
[100%] Built target main

(PWD) pico-examples/build/pico-azure-iot-sdk-c
$ cp main.uf2 /f/



2.4. 📝 Sample application results

2.4.1. 📬 "iothub_ll_telemetry_sample" application result

📑 Let's see this doc for iothub_ll_telemetry_sample application

2.4.2. 📩 "iothub_ll_c2d_sample" application result

📑 Let's see this doc for iothub_ll_c2d_sample application

2.4.3. 🔐 "iothub_ll_client_x509_sample" application result

📑 Let's see this doc for iothub_ll_client_x509_sample application

2.4.4. 🚢 "prov_dev_client_ll_sample" application result

📑 Let's see this doc for prov_dev_client_ll_sample application
